R-410A SEALED SYSTEM REPAIR
Replace 9k, 12k, and18k Cassette Type unit Compressor and Motor
Replacement of Fan Motor
Step
Illustration
Handli ng Instruction
6.
Remov
e the motor
and replac e it
Remove the motor and
replace it.
7.
Tighten the bolts
holding the motor
Use a wrench or
socket to carefully
tighten the motor bolts.
8.
Mount the fan blade
and tighten the bolt
9. Reinstall the condensate
pan and tighten the screws
Mount the fan blade and
use a wrench or socket to
carefully tighten the bolt
holding the fan blade in
place. D o not overtighten
as dam age may occur.
Use a screwdriver to
carefully tighten the screws
holding the condensat e
pan in place. T ake care to
not overtighten as dam age
to pan will occur.
