Friedrich FPHMR36A3A Service Manual

119 PB
R-410A SEALED SYSTEM REPAIR
Replace 24k and 36k Cassette Compesdsor and Motor Type unit Compressor and Motor
Step Illustration Handling Instruction
1. Loosen the screws
holding the electric box
cover and electric box.
Use screwdriver to loosen
the Electric box.
2. Loosen the screws
holding condensat e pan
and Remove the
condensate pan.
Use screwdriver to loosen
the screws holding the drain
pan in place.
3. Loosen the bolts holding
the fan blade s in place and
Remove the fan blade.
Use a wrench or socket to
carefully remove the fan
blade bolts.
4. Loosen the screws
holding the motor in place
and Remove the motor and
replace it.
Use screwdriver to loosen
the screws holding the
motor.
