Part 2 Product data_Outdoor units
7. Capacity tables
Models : MR24DY3JMA
n Non ducted type indoor unit
Cooling capacity
Notes:
1.
Capacities are based on the following conditions.
Corresponding refrigerant piping length : 25ft , Level difference : 0ft
2. TC : Total Capacity (kBtu/h), PI : Power Input (kW)
3. indicates reference data. When operating at this temperature,
these values can be different by discontinuous operation.
14 19.61 0.93 20.82 0.96 22.04 1.00 22.92 1.01 24.48 1.03 25.69 1.05
20 19.59 0.94 20.81 0.97 22.02 1.01 22.90 1.02 24.46 1.04 25.67 1.06
25 19.58 0.95 20.79 0.99 22.01 1.02 22.89 1.04 24.44 1.06 25.65 1.08
30 19.56 0.97 20.78 1.00 21.99 1.04 22.87 1.05 24.42 1.07 25.64 1.09
35 19.55 0.98 20.76 1.02 21.97 1.05 22.85 1.07 24.40 1.09 25.62 1.11
40 19.53 0.99 20.74 1.03 21.96 1.07 22.83 1.08 24.38 1.10 25.60 1.12
45 19.52 1.01 20.73 1.04 21.94 1.08 22.82 1.09 24.36 1.11 25.58 1.14
50 19.50 1.02 20.71 1.06 21.92 1.10 22.80 1.11 24.35 1.13 25.56 1.15
55 19.49 1.03 20.70 1.07 21.91 1.11 22.78 1.12 24.33 1.14 25.54 1.17
60 19.47 1.05 20.68 1.08 21.89 1.12 22.76 1.14 24.31 1.16 25.52 1.18
65 19.46 1.06 20.66 1.10 21.87 1.14 22.75 1.15 24.29 1.17 25.50 1.20
70 19.44 1.07 20.65 1.11 21.86 1.15 22.73 1.17 24.27 1.19 25.48 1.21
75 18.97 1.13 20.18 1.17 21.38 1.22 22.25 1.23 23.79 1.25 25.00 1.28
80 18.51 1.19 19.71 1.23 20.91 1.28 21.78 1.29 23.31 1.32 24.51 1.34
85 18.04 1.25 19.24 1.29 20.44 1.34 21.30 1.36 22.84 1.38 24.03 1.41
90 17.58 1.30 18.77 1.35 19.97 1.40 20.83 1.42 22.36 1.44 23.56 1.47
95 17.08 1.36 18.26 1.41 19.45 1.46 20.00 1.48 21.83 1.51 23.02 1.54
100 16.66 1.42 17.85 1.47 19.04 1.53 19.74 1.54 21.42 1.57 22.61 1.60
105 16.24 1.48 17.43 1.53 18.62 1.59 19.48 1.61 21.00 1.64 22.19 1.67
110 15.83 1.54 17.02 1.59 18.21 1.65 19.07 1.67 20.59 1.70 21.78 1.74
115 15.41 1.59 16.60 1.65 17.79 1.71 18.65 1.73 20.17 1.77 21.36 1.80
118 15.16 1.63 16.35 1.69 17.54 1.75 18.40 1.77 19.92 1.80 21.11 1.84
122 15.08 1.68 16.27 1.74 17.46 1.80 18.32 1.82 19.84 1.85 21.03 1.89
14 19.61 0.93 20.82 0.96 22.04 1.00 22.92 1.01 24.48 1.03 25.69 1.05
20 19.59 0.94 20.81 0.97 22.02 1.01 22.90 1.02 24.46 1.04 25.67 1.06
25 19.58 0.95 20.79 0.99 22.01 1.02 22.89 1.04 24.44 1.06 25.65 1.08
30 19.56 0.97 20.78 1.00 21.99 1.04 22.87 1.05 24.42 1.07 25.64 1.09
35 19.55 0.98 20.76 1.02 21.97 1.05 22.85 1.07 24.40 1.09 25.62 1.11
40 19.53 0.99 20.74 1.03 21.96 1.07 22.83 1.08 24.38 1.10 25.60 1.12
45 19.52 1.01 20.73 1.04 21.94 1.08 22.82 1.09 24.36 1.11 25.58 1.14
50 19.50 1.02 20.71 1.06 21.92 1.10 22.80 1.11 24.35 1.13 25.56 1.15
55 19.49 1.03 20.70 1.07 21.91 1.11 22.78 1.12 24.33 1.14 25.54 1.17
60 19.47 1.05 20.68 1.08 21.89 1.12 22.76 1.14 24.31 1.16 25.52 1.18
65 19.46 1.06 20.66 1.10 21.87 1.14 22.75 1.15 24.29 1.17 25.50 1.20
70 19.44 1.07 20.65 1.11 21.86 1.15 22.73 1.17 24.27 1.19 25.48 1.21
75 18.97 1.13 20.18 1.17 21.38 1.22 22.25 1.23 23.79 1.25 25.00 1.28
80 18.51 1.19 19.71 1.23 20.91 1.28 21.78 1.29 23.31 1.32 24.51 1.34
85 18.04 1.25 19.24 1.29 20.44 1.34 21.30 1.36 22.84 1.38 24.03 1.41
90 17.58 1.30 18.77 1.35 19.97 1.40 20.83 1.42 22.36 1.44 23.56 1.47
95 17.08 1.36 18.26 1.41 19.45 1.46 20.00 1.48 21.83 1.51 23.02 1.54
100 16.66 1.42 17.85 1.47 19.04 1.53 19.74 1.54 21.42 1.57 22.61 1.60
105 16.24 1.48 17.43 1.53 18.62 1.59 19.48 1.61 21.00 1.64 22.19 1.67
110 15.83 1.54 17.02 1.59 18.21 1.65 19.07 1.67 20.59 1.70 21.78 1.74
115 15.41 1.59 16.60 1.65 17.79 1.71 18.65 1.73 20.17 1.77 21.36 1.80
118 15.16 1.63 16.35 1.69 17.54 1.75 18.40 1.77 19.92 1.80 21.11 1.84
122 15.08 1.68 16.27 1.74 17.46 1.80 18.32 1.82 19.84 1.85 21.03 1.89
TC PI TC PI TC PI TC PI TC PI TC PI
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
Combination
Capacity Index
Outdoor Air
Temp.: °FDB
Operation
68 / 57 73 / 61 77 / 64 80 / 67 86 / 72 90 / 75
Indoor Air Temp. °F DB / °F WB
3 UNITS
9 + 9 + 12
9 + 12 + 12
