18 _ Multiple piping type
MULTI ZONEMULTI ZONE
Part 2 Product data_Outdoor units
7. Capacity tables
Models : MR24DY3JMA
n Non ducted type indoor unit
Heating capacity
Operation
Combination
Capacity Index
(kBtu/h)
Outdoor Air
Temp.
Indoor Air Temp.: °FDB
61 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
°F DB °F WB kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
-4 -4.4 6.35 1.32 5.83 1.37 5.83 1.39 5.77 1.40 5.72 1.40 5.46 1.46
0 -0.4 8.08 1.33 7.58 1.38 7.47 1.40 7.37 1.41 7.29 1.42 6.98 1.48
5 4.5 10.14 1.34 9.66 1.39 9.43 1.42 9.28 1.44 9.16 1.45 8.79 1.50
10 9 11.52 1.35 11.05 1.40 10.74 1.44 10.56 1.46 10.41 1.47 10.00 1.52
17 15 13.03 1.37 12.58 1.41 12.18 1.46 11.96 1.48 11.79 1.50 11.33 1.55
20 19 13.95 1.38 13.51 1.42 13.06 1.47 12.81 1.50 12.62 1.52 12.14 1.56
25 23 15.49 1.40 15.03 1.44 14.51 1.50 14.23 1.53 14.01 1.55 13.49 1.59
30 28 17.04 1.43 16.51 1.48 15.95 1.52 15.65 1.56 15.42 1.58 14.85 1.62
35 32 18.59 1.46 18.00 1.51 17.38 1.55 17.07 1.59 16.82 1.62 16.21 1.65
40 36 19.54 1.50 18.99 1.55 18.38 1.60 18.06 1.63 17.81 1.66 17.16 1.70
45 41 20.72 1.56 20.23 1.61 19.63 1.66 19.30 1.69 19.04 1.71 18.35 1.76
47 43 21.19 1.58 20.72 1.63 20.13 1.68 19.80 1.71 19.54 1.73 18.83 1.79
50 46 21.26 1.57 20.83 1.61 20.31 1.66 20.02 1.69 19.78 1.71 19.11 1.75
55 51 21.36 1.55 21.01 1.59 20.62 1.63 20.38 1.64 20.19 1.66 19.59 1.70
60 56 21.46 1.53 21.18 1.56 20.92 1.59 20.75 1.60 20.60 1.61 20.08 1.64
63 59 21.53 1.52 21.29 1.55 21.11 1.57 20.96 1.58 20.85 1.59 20.36 1.60
68 64 21.59 1.51 21.40 1.53 21.29 1.55 21.18 1.56 21.10 1.56 20.66 1.57
-4 -4.4 7.40 1.46 6.80 1.51 6.80 1.53 6.73 1.54 6.67 1.55 6.36 1.61
0 -0.4 9.43 1.47 8.84 1.52 8.72 1.55 8.60 1.56 8.51 1.57 8.14 1.63
5 4.5 11.83 1.48 11.27 1.54 11.00 1.57 10.83 1.59 10.69 1.60 10.25 1.66
10 9 13.44 1.50 12.89 1.55 12.53 1.59 12.32 1.61 12.14 1.63 11.67 1.68
17 15 15.20 1.51 14.68 1.56 14.21 1.61 13.96 1.64 13.75 1.66 13.22 1.71
20 19 16.28 1.53 15.76 1.57 15.23 1.63 14.95 1.66 14.72 1.68 14.16 1.73
25 23 18.07 1.55 17.54 1.60 16.93 1.66 16.61 1.69 16.35 1.72 15.73 1.76
30 28 19.88 1.58 19.26 1.63 18.60 1.68 18.26 1.72 17.99 1.75 17.33 1.80
35 32 21.69 1.61 21.00 1.67 20.28 1.71 19.92 1.75 19.63 1.79 18.92 1.83
40 36 22.79 1.66 22.15 1.72 21.45 1.77 21.07 1.80 20.78 1.83 20.02 1.88
45 41 24.17 1.72 23.60 1.78 22.90 1.83 22.52 1.87 22.22 1.89 21.41 1.95
47 43 24.73 1.74 24.17 1.80 23.48 1.86 23.10 1.89 22.79 1.92 21.96 1.97
50 46 24.80 1.73 24.30 1.78 23.70 1.84 23.35 1.86 23.08 1.89 22.30 1.94
55 51 24.92 1.71 24.51 1.76 24.05 1.80 23.78 1.82 23.56 1.83 22.86 1.87
60 56 25.04 1.70 24.72 1.73 24.41 1.76 24.20 1.77 24.04 1.78 23.42 1.81
63 59 25.11 1.68 24.84 1.71 24.63 1.74 24.46 1.75 24.32 1.75 23.76 1.77
68 64 25.19 1.67 24.97 1.69 24.84 1.71 24.71 1.72 24.61 1.72 24.10 1.74
-4 -4.4 7.69 1.50 7.07 1.55 7.06 1.57 6.99 1.59 6.93 1.59 6.61 1.65
0 -0.4 9.79 1.51 9.19 1.56 9.06 1.59 8.94 1.60 8.84 1.62 8.46 1.67
5 4.5 12.29 1.52 11.71 1.58 11.43 1.61 11.25 1.63 11.10 1.64 10.65 1.70
10 9 13.96 1.54 13.39 1.59 13.02 1.63 12.80 1.65 12.62 1.67 12.12 1.72
17 15 15.80 1.55 15.25 1.60 14.77 1.65 14.50 1.68 14.29 1.70 13.74 1.75
20 19 16.91 1.57 16.37 1.61 15.83 1.67 15.53 1.70 15.30 1.73 14.72 1.77
25 23 18.78 1.59 18.22 1.64 17.59 1.70 17.25 1.73 16.99 1.76 16.35 1.81
30 28 20.65 1.62 20.02 1.68 19.33 1.73 18.97 1.77 18.69 1.80 18.00 1.84
35 32 22.53 1.66 21.82 1.71 21.07 1.76 20.69 1.80 20.39 1.83 19.65 1.88
40 36 23.68 1.70 23.02 1.76 22.28 1.81 21.90 1.85 21.59 1.88 20.81 1.93
45 41 25.12 1.76 24.52 1.82 23.79 1.88 23.40 1.91 23.08 1.94 22.24 2.00
47 43 25.69 1.79 25.12 1.85 24.40 1.91 24.00 1.94 23.68 1.97 22.82 2.03
50 46 25.77 1.78 25.25 1.83 24.62 1.88 24.26 1.91 23.98 1.93 23.17 1.99
55 51 25.89 1.76 25.46 1.80 24.99 1.85 24.71 1.87 24.48 1.88 23.75 1.92
60 56 26.02 1.74 25.68 1.77 25.36 1.81 25.15 1.82 24.97 1.83 24.33 1.86
63 59 26.09 1.73 25.81 1.76 25.59 1.78 25.41 1.79 25.27 1.80 24.68 1.82
68 64 26.17 1.72 25.94 1.74 25.81 1.76 25.68 1.76 25.57 1.77 25.04 1.78
2 UNIT
9 + 9
9 + 12
12 + 12
