Part 2 Product data_Outdoor units
7. Capacity tables
Models : MR24DY3JMA
n Non ducted type indoor unit
Heating capacity
Operation
Combination
Capacity Index
(kBtu/h)
Outdoor Air
Temp.
Indoor Air Temp.: °FDB
61 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
°F DB °F WB
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
-4 -4.4 7.69 1.50 7.07 1.55 7.06 1.57 6.99 1.59 6.93 1.59 6.61 1.65
0 -0.4 9.79 1.51 9.19 1.56 9.06 1.59 8.94 1.60 8.84 1.62 8.46 1.67
5 4.5 12.29 1.52 11.71 1.58 11.43 1.61 11.25 1.63 11.10 1.64 10.65 1.70
10 9 13.96 1.54 13.39 1.59 13.02 1.63 12.80 1.65 12.62 1.67 12.12 1.72
17 15 15.80 1.55 15.25 1.60 14.77 1.65 14.50 1.68 14.29 1.70 13.74 1.75
20 19 16.91 1.57 16.37 1.61 15.83 1.67 15.53 1.70 15.30 1.73 14.72 1.77
25 23 18.78 1.59 18.22 1.64 17.59 1.70 17.25 1.73 16.99 1.76 16.35 1.81
30 28 20.65 1.62 20.02 1.68 19.33 1.73 18.97 1.77 18.69 1.80 18.00 1.84
35 32 22.53 1.66 21.82 1.71 21.07 1.76 20.69 1.80 20.39 1.83 19.65 1.88
40 36 23.68 1.70 23.02 1.76 22.28 1.81 21.90 1.85 21.59 1.88 20.81 1.93
45 41 25.12 1.76 24.52 1.82 23.79 1.88 23.40 1.91 23.08 1.94 22.24 2.00
47 43 25.69 1.79 25.12 1.85 24.40 1.91 24.00 1.94 23.68 1.97 22.82 2.03
50 46 25.77 1.78 25.25 1.83 24.62 1.88 24.26 1.91 23.98 1.93 23.17 1.99
55 51 25.89 1.76 25.46 1.80 24.99 1.85 24.71 1.87 24.48 1.88 23.75 1.92
60 56 26.02 1.74 25.68 1.77 25.36 1.81 25.15 1.82 24.97 1.83 24.33 1.86
63 59 26.09 1.73 25.81 1.76 25.59 1.78 25.41 1.79 25.27 1.80 24.68 1.82
68 64 26.17 1.72 25.94 1.74 25.81 1.76 25.68 1.76 25.57 1.77 25.04 1.78
-4 -4.4 7.69 1.50 7.07 1.55 7.06 1.57 6.99 1.59 6.93 1.59 6.61 1.65
0 -0.4 9.79 1.51 9.19 1.56 9.06 1.59 8.94 1.60 8.84 1.62 8.46 1.67
5 4.5 12.29 1.52 11.71 1.58 11.43 1.61 11.25 1.63 11.10 1.64 10.65 1.70
10 9 13.96 1.54 13.39 1.59 13.02 1.63 12.80 1.65 12.62 1.67 12.12 1.72
17 15 15.80 1.55 15.25 1.60 14.77 1.65 14.50 1.68 14.29 1.70 13.74 1.75
20 19 16.91 1.57 16.37 1.61 15.83 1.67 15.53 1.70 15.30 1.73 14.72 1.77
25 23 18.78 1.59 18.22 1.64 17.59 1.70 17.25 1.73 16.99 1.76 16.35 1.81
30 28 20.65 1.62 20.02 1.68 19.33 1.73 18.97 1.77 18.69 1.80 18.00 1.84
35 32 22.53 1.66 21.82 1.71 21.07 1.76 20.69 1.80 20.39 1.83 19.65 1.88
40 36 23.68 1.70 23.02 1.76 22.28 1.81 21.90 1.85 21.59 1.88 20.81 1.93
45 41 25.12 1.76 24.52 1.82 23.79 1.88 23.40 1.91 23.08 1.94 22.24 2.00
47 43 25.69 1.79 25.12 1.85 24.40 1.91 24.00 1.94 23.68 1.97 22.82 2.03
50 46 25.77 1.78 25.25 1.83 24.62 1.88 24.26 1.91 23.98 1.93 23.17 1.99
55 51 25.89 1.76 25.46 1.80 24.99 1.85 24.71 1.87 24.48 1.88 23.75 1.92
60 56 26.02 1.74 25.68 1.77 25.36 1.81 25.15 1.82 24.97 1.83 24.33 1.86
63 59 26.09 1.73 25.81 1.76 25.59 1.78 25.41 1.79 25.27 1.80 24.68 1.82
68 64 26.17 1.72 25.94 1.74 25.81 1.76 25.68 1.76 25.57 1.77 25.04 1.78
-4 -4.4 7.69 1.39 7.07 1.44 7.06 1.46 6.99 1.47 6.93 1.48 6.61 1.53
0 -0.4 9.79 1.40 9.19 1.45 9.06 1.48 8.94 1.49 8.84 1.50 8.46 1.55
5 4.5 12.29 1.41 11.71 1.46 11.43 1.49 11.25 1.51 11.10 1.53 10.65 1.58
10 9 13.96 1.43 13.39 1.47 13.02 1.51 12.80 1.53 12.62 1.55 12.12 1.60
17 15 15.80 1.44 15.25 1.49 14.77 1.53 14.50 1.56 14.29 1.58 13.74 1.63
20 19 16.91 1.45 16.37 1.50 15.83 1.55 15.53 1.58 15.30 1.60 14.72 1.65
25 23 18.78 1.48 18.22 1.52 17.59 1.58 17.25 1.61 16.99 1.63 16.35 1.68
30 28 20.65 1.51 20.02 1.56 19.33 1.60 18.97 1.64 18.69 1.67 18.00 1.71
35 32 22.53 1.54 21.82 1.59 21.07 1.63 20.69 1.67 20.39 1.70 19.65 1.74
40 36 23.68 1.58 23.02 1.64 22.28 1.68 21.90 1.72 21.59 1.75 20.81 1.79
45 41 25.12 1.64 24.52 1.69 23.79 1.74 23.40 1.78 23.08 1.80 22.24 1.85
47 43 25.69 1.66 25.12 1.71 24.40 1.77 24.00 1.80 23.68 1.82 22.82 1.88
50 46 25.77 1.65 25.25 1.70 24.62 1.75 24.26 1.77 23.98 1.80 23.17 1.84
55 51 25.89 1.63 25.46 1.67 24.99 1.71 24.71 1.73 24.48 1.75 23.75 1.78
60 56 26.02 1.61 25.68 1.65 25.36 1.68 25.15 1.69 24.97 1.70 24.33 1.72
63 59 26.09 1.60 25.81 1.63 25.59 1.65 25.41 1.66 25.27 1.67 24.68 1.69
68 64 26.17 1.59 25.94 1.61 25.81 1.63 25.68 1.64 25.57 1.64 25.04 1.65
2 UNIT
3 UNIT
9 + 18
12 + 18
9 + 9 + 9
To Next Page
