ROUTINE MAINTENANCE (Continued)
Standard lter cleaning, removal and installation instructions
STEP 1.
STEP 2.
FILTER
FILTER
GRIP
STEP 2. Swing the front frame open. Clean the front frame by washing
STEP 1.
NOTE:
HANDLE
FILTER
GRIP
TOP TAB
FRONT
FRAME WITH
STANDARD
MESH FILTER
A
Figure 1
Figure 3
Figure 4
Figure 2
STEP 1.
3
Do not force the filter into the unit.
Remove the filter by grabbing it from its handle, lifting it up and swinging
it out.
Removing filter Filter dissassembly and cleaning
Filter assembly
( )
Filter installation
onto the filter frame.
Install the filter back into the unit by sliding the filter halfway up,
tilt towards the front of you, then gently slide it up fully.
