Friedrich YM18J34A - Performance Data (Cooling & Heating) ES - EM - EL - EK Models

TTJ-0198 (10/97) (Page 13 of 64)
PERFORMANCE EVAPORATOR AIR OPERATING ELECTRICAL R-22 COMP.
DATA* TEMP. °F. PRESSURES RATINGS REFRIG. OIL
Cooling DISCHARGE TEMP. SUCTION DISCHARGE AMPS LOCKED CHARGE IN CHARGE IN
AIR DROP °F ROTOR AMPS OZ. FLUID OZ.
ES12J33 58.0 22.0 77.5 266 5.5 26.3 26.0 11.8
5.7
ES15J33A 53.0 27.0 77.0 260 7.4 42.0 49.0 30.0
8.2
EM18J34A 55.0 25.0 73.0 262 8.2 42.0 49.0 30.0
8.7
EL24J35A 55.0 25.0 73.5 280 12.0 61.0 53.0 32.0
13.3
EL33J35 52.0 28.0 71.0 299 17.0 94.0 81.0 35.0
18.0
EK12J33A 57.0 23.0 79.0 293 5.8 26.3 26.0 11.8
6.2
EK18J33A 55.0 25.0 73.0 262 8.2 42.0 46.0 30.0
8.8
* Rating Conditions: 80°F Room Air Temperature and 50% Relative Humidity with
95°F Outside Air Temperature at 40% Relative Humidity.
PERFORMANCE DATA VOLTS BTUH CFM HEAT RISE
Heating HIGH SPEED
ES12J33 230 10700 1120 30.5
208 8900
ES15J33A 230 10700 1100 30.5
208 8900
EM18J34A 230 13000 1120 28.3
208 10600
EL24J35A 230 17300 1100 28.6
208 14300
EL33J35 230 17300 1110 22.8
208 14300
EK12J33A 230 10700 1080 30.5
208 8900
EK18J34A 230 13000 1120 27.5
208 10600
