TTJ-0198 (10/97) (Page 41 of 64)

"YS" - "YM" - "YL" SERIES PARTS LIST

REF. PART NO. DESCRIPTION APPLICATION

YYYY

SSML

0112

9384

JJJJ

1333

0345

ELECTRICAL PARTS

1 615-628-07 Compressor, Tecumseh, 115 V, 60 Hz, 1 Ph, Model RK5480E ....... 1

1 615-628-05 Compressor, Tecumseh, 230/208 V, 60 Hz, 1 Ph, Model RK5513E 1

1 617-187-01

Compressor, Bristol, 230/208 V, 60 Hz,1 Ph, Model H23B175ABCC .

1 611-935-47

Compressor, Tecumseh, 230/208 V, 60 Hz, 1 Ph, Model AWF5524EXN

* 603-645-94 Overload, Compressor - MRA3793-114 ......................................... 1

* 603-645-97 Overload, Compressor - MRA3795-114 ......................................... 1

2 610-714-93 Motor, Fan ...................................................................................... 1

2 610-714-94 Motor, Fan ...................................................................................... 1

] 2 610-714-96 Motor, Fan ...................................................................................... 1

2 610-714-85 Motor, Fan ...................................................................................... 1

3 605-000-54 Cord, Electric Supply - 15 Amp, 125 Volt ........................................ 1

3 605-000-49 Cord, Electric Supply - 20 Amp, 250 Volt ........................................ 1

3 605-000-48 Cord, Electric Supply - 30 Amp, 250 Volt ........................................ 1

3 605--000-55 Cord, Electric Supply - 30 Amp, 250 Volt ........................................ 1

4 606-072-04 Switch, System - 8 Position ............................................................ 1 1 1 1

5 618-061-00 Switch, Rocker (Yes-No) ................................................................ 1 1 1 1

6 618-224-00 Thermostat (Cool & Heat) .............................................................. 1 1 1 1

* 613-503-13 Thermostat, Defrost ....................................................................... 1 1 1 1

7 610-803-38 Capacitor - 25/10 MFD, 370 V ........................................................ 1

7 610-803-37 Capacitor - 25/7.5 MFD, 370 V ....................................................... 1

7 610-803-36 Capacitor - 30/7.5 MFD, 370 V ....................................................... 1

7 610-803-34 Capacitor - 35/7.5 MFD, 370 V ....................................................... 1

* 618-208-00 Wire Harness, Fan Motor ............................................................... 1 1 1 1

* 618-213-00 Wire Harness, Compressor............................................................ 1 1

* 618-213-02 Wire Harness, Compressor............................................................ 1

* 618-214-00 Wire Harness, Compressor............................................................ 1

* 618-211-00 Wire Harness, Compressor............................................................ 1

* 618-624-08 Wire Harness, Solenoid.................................................................. 1 1 1 1

8 618-080-00 Resistor Block - 115 Volt ................................................................ 1

8 618-080-01 Resistor Block - 230 Volt ................................................................ 1 1 1

9 618-786-00 Heater Element - 3.3 KW ............................................................... 1

9 618-786-01 Heater Element - 4.0 KW ............................................................... 1

9 618-786-02 Heater Element - 5.2 KW ............................................................... 1

* 250-188-00 Solenoid - 120 Volt ......................................................................... 1

* 210-586-43 Solenoid - 230 Volt ......................................................................... 1 1 1

* 615-963-01 Fuse Link ....................................................................................... 1 1 1

* 618-279-00 Heater Limit....................................................................................

REFRIGERATION SYSTEM COMPONENTS

10 618-501-00 Coil, Evaporator ............................................................................. 1 1

10 618-500-01 Coil, Evaporator ............................................................................. 1

* Not Shown
