TTJ-0198 (10/97) (Page 48 of 64)
"ES" - "EM" SERIES PARTS LIST
REF. PART NO. DESCRIPTION APPLICATION
EEE
SSM
111
258
JJJ
333
334
AA
ELECTRICAL PARTS
1 615-628-04 Compressor, Tecumseh, 230 V, 60 Hz, 1 Ph, Model RK5512E .............. 1
1 615-628-28 Compressor, Tecumseh, 230 V, 60 Hz, 1 Ph, Model RK5515E .............. 1
1 617-187-01 Compressor, Bristol, 230 V, 60 Hz, 1 Ph, Model H23B175ABCC .......... 1
* 603-645-96 Overload, Compressor - MRA3794-114 ................................................ 1
* 617-645-06 Overload, Compressor - MRA4764-114 ................................................ 1
2 610-714-94 Motor, Fan ............................................................................................. 1
2 610-714-95 Motor, Fan ............................................................................................. 1
2 610-714-96 Motor, Fan ............................................................................................. 1
3 605-000-49 Cord, Electric Supply - 20 Amp, 250 V .................................................. 1 1
3 605-000-48 Cord, Electric Supply - 30 Amp, 250 V .................................................. 1
4 604-416-06 Switch, System - 8 Position ................................................................... 1 1 1
5 618-061-00 Switch, Rocker (Yes-No) ....................................................................... 1 1 1
6 618-224-00 Thermostat (Cool & Heat) ..................................................................... 1 1 1
7 610-803-37 Capacitor - 25/7.5 MFD, 370 V .............................................................. 1 1
7 610-803-36 Capacitor - 30/7.5 MFD, 370 V .............................................................. 1
* 618-208-00 Wire Harness, Fan Motor ...................................................................... 1 1 1
* 618-213-00 Wire Harness, Compressor................................................................... 1
* 618-214-00 Wire Harness, Compressor................................................................... 1
* 618-213-02 Wire Harness, Compressor................................................................... 1
8 618-080-01 Resistor Block - 230 V ........................................................................... 1 1 1
9 618-786-00 Heater Element - 3.3 KW ...................................................................... 1 1
9 618-786-01 Heater Element - 4.0 KW ...................................................................... 1
* 618-963-01 Fuse Link .............................................................................................. 1 1 1
* 618-279-00 Heater Limit........................................................................................... 1 1 1
REFRIGERATION SYSTEM COMPONENTS
10 618-501-00 Coil, Evaporator .................................................................................... 1
10 618-500-05 Coil, Evaporator .................................................................................... 1
10 618-500-01 Coil, Evaporator .................................................................................... 1
11 618-503-02 Coil, Condenser .................................................................................... 1 1
11 618-502-00 Coil, Condenser .................................................................................... 1
* 01390000 Capillary Tube - .064 I.D. x 40" Long...................................................... 1
* 03760512 Capillary Tube - .064 I.D. x 35" Long...................................................... 1
* 03760548 Capillary Tube - .054 I.D. x 37 1/4" - 40" Long ....................................... 2
* 603-081-01 Filter Drier (Install during sealed system repair) .................................... 1 1 1
CHASSIS PARTS
12 618-129-00 Shield, Bottom....................................................................................... 1 1
12 618-129-01 Shield, Bottom....................................................................................... 1
* 618-218-00 Shield, Side ........................................................................................... 1 1
* 618-218-01 Shield, Side ........................................................................................... 1
* Not Shown
To Next Page
