Friedrich YM18J34A - Page 49

TTJ-0198 (10/97) (Page 49 of 64)
"ES" - "EM" SERIES PARTS LIST
REF. PART NO. DESCRIPTION APPLICATION
EEE
SSM
111
258
JJJ
333
334
AA
CHASSIS PARTS
13 618-189-00 Bracket, Heater Mounting...................................................................... 1 1 1
14 614-939-05 Knob, Control ........................................................................................ 2 2 2
15 618-072-00 Panel, Control Mounting ........................................................................ 1 1
15 618-110-00 Panel, Control Mounting ........................................................................ 1
* 600-713-11 Bushing, Snap....................................................................................... 1 1 1
* 600-713-12 Bushing, Snap....................................................................................... 1 1 1
* 618-170-00 Insulation, Left Side............................................................................... 1 1
* 618-170-01 Insulation, Left Side............................................................................... 1
16 618-027-00 Panel, Left Side ..................................................................................... 1 1
16 618-042-00 Panel, Left Side ..................................................................................... 1
17 618-028-01 Partition, Control Box ............................................................................ 1 1
17 618-043-01 Partition, Control Box ............................................................................ 1
18 618-204-00 Bracket, Capacitor Mounting ................................................................. 1 1 1
19 618-207-00 Strap, Capacitor .................................................................................... 1 1 1
20 618-233-00 Decorative Panel ................................................................................... 1 1 1
* 618-076-00 Grommet, Suction Line.......................................................................... 1 1 1
* 618-148-00 Connector, Fresh Air & Exhaust ............................................................ 1 1 1
21 618-172-00 Cover, Top ............................................................................................. 1 1 1
22 618-167-00 Insulation, Top Cover ............................................................................. 1 1 1
* 618-168-00 Insulation, Left Side Deck...................................................................... 1 1 1
23 618-171-00 Deck...................................................................................................... 1 1 1
* 608-658-08 Filter, Air ................................................................................................ 1 1
* 608-658-09 Filter, Air ................................................................................................ 1
* 618-230-00 Holder, Filter.......................................................................................... 2 2 2
24 618-202-00 Airfoil ..................................................................................................... 1 1 1
* 618-206-00 Bracket, Resistor Block ......................................................................... 1 1 1
* 915-003-02 Clamp, Supply Cord .............................................................................. 1 1 1
25 605-420-03 Fan Blade .............................................................................................. 1 1
25 605-420-04 Fan Blade .............................................................................................. 1
26 606-106-03 Blower Wheel ........................................................................................ 1
26 606-106-01 Blower Wheel ........................................................................................ 1
26 606-106-05 Blower Wheel ........................................................................................ 1
27 618-033-00 Inner Wall .............................................................................................. 1 1
27 618-047-00 Inner Wall .............................................................................................. 1
28 618-025-00 Mount, Motor ......................................................................................... 1 1
28 618-041-00 Mount, Motor ......................................................................................... 1
29 618-036-00 Shroud .................................................................................................. 1 1
29 618-049-00 Shroud .................................................................................................. 1
30 618-026-00 Brace, Shroud ....................................................................................... 3 3 3
31 618-169-00 Insulation, Inner Wall ............................................................................. 1 1
31 618-169-01 Insulation, Inner Wall ............................................................................. 1
32 618-173-00 Blower Front .......................................................................................... 1 1
32 618-174-00 Blower Front .......................................................................................... 1
* Not Shown
