Friedrich YM18J34A - Page 50

TTJ-0198 (10/97) (Page 50 of 64)
"ES" - "EM" SERIES PARTS LIST
REF. PART NO. DESCRIPTION APPLICATION
EEE
SSM
111
258
JJJ
333
334
AA
CHASSIS PARTS (Cont.)
33 618-149-00 Scroll ..................................................................................................... 1 1
33 618-175-00 Scroll ..................................................................................................... 1
34 618-215-00 Door, Slide Assembly ............................................................................ 1 1 1
35 618-090-01 Base Pan............................................................................................... 1 1
35 618-090-09 Base Pan............................................................................................... 1
* 618-038-00 Drain Pan .............................................................................................. 1 1 1
* 601-799-00 Bellows, Drain Valve .............................................................................. 1 1 1
* 618-188-00 Grille Assembly (Rear) .......................................................................... 1 1
* 618-188-01 Grille Assembly (Rear) .......................................................................... 1
36 610-289-00 Grommet, Compressor.......................................................................... 3 3 3
37 914-004-00 Bolt, Compressor Mounting................................................................... 3 3 3
38 618-102-00 Plenum Assembly ................................................................................. 1 1 1
* 618-093-00 Knob, Fresh Air & Exhaust .................................................................... 1 1 1
* 618-092-00 Lever, Fresh Air & Exhaust .................................................................... 1 1 1
* 618-062-00 Connector, Louver ................................................................................. 2 2 2
* 618-063-00 Louver ................................................................................................... 20 20 20
* 618-063-01 Louver with Handle................................................................................ 2 2 2
39 618-257-00 Outer Shell (Carton with Sill Plate) ........................................................ 1 1
39 618-257-01 Outer Shell (Carton with Sill Plate) ........................................................ 1
40 618-084-01 Sill Plate ................................................................................................ 1 1 1
* 618-196-00 Guide, Shell........................................................................................... 2 2 2
41 618-089-00 Grille, Intake .......................................................................................... 1 1
41 618-111-00 Grille, Intake .......................................................................................... 1
* 618-199-00 Latch, Intake Grille ................................................................................ 2 2 2
42 602-944-08 Wingboard............................................................................................. 1 1
42 602-944-09 Wingboard............................................................................................. 1
* 611-050-04 Accessory Package............................................................................... 1 1
* 611-050-05 Accessory Package............................................................................... 1
43 611-095-03 Bracket, Support ................................................................................... 2 2 2
44 618-197-01 Angle, Wingboard (Top)......................................................................... 1 1 1
45 618-198-01 Angle, Wingboard (Side) ....................................................................... 2 2
45 618-198-03 Angle, Wingboard (Side) ....................................................................... 2
46 606-103-03 Gasket (Vinyl)........................................................................................ 1 1 1
* 617-173-01 Gasket (Foam) ...................................................................................... 1 1 1
* 608-460-16 Bag Assembly (Hardware) .................................................................... 1 1 1
* 618-116-03 Carton (Shipping) .................................................................................. 1 1
* 618-116-04 Carton (Shipping) .................................................................................. 1
* 618-139-00 Pad, Shipping (Bottom) ......................................................................... 1 1 1
* 618-141-01 Pad, Shipping (Top) ............................................................................... 1 1 1
* 618-118-00 Tube, Shipping (Front & Rear) ............................................................... 2 2
* 618-118-01 Tube, Shipping (Front & Rear) ............................................................... 2
47 600-733-00 Gasket, Window (Foam) ........................................................................ 1 1 1
* Not Shown
