Friedrich YM18J34A - Page 55

TTJ-0198 (10/97) (Page 55 of 64)
"EL" SERIES PARTS LIST
REF. PART NO. DESCRIPTION APPLICATION
EE
LL
23
43
JJ
33
55
CHASSIS PARTS (Cont.) A
21 618-179-00 Cover, Top .............................................................................................. 1 1
22 618-182-00 Insulation, Top Cover .............................................................................. 1 1
* 618-183-00 Insulation, Left Side Deck....................................................................... 1 1
23 618-180-00 Deck....................................................................................................... 1 1
* 608-658-10 Filter, Air ................................................................................................. 1 1
* 618-230-00 Holder, Filter........................................................................................... 2 2
24 618-202-01 Airfoil ...................................................................................................... 1 1
* 618-206-00 Bracket, Resistor Block .......................................................................... 1 1
* 915-003-02 Clamp, Supply Cord ............................................................................... 1 1
25 605-420-01 Fan Blade ............................................................................................... 1 1
26 606-106-05 Blower Wheel ......................................................................................... 1
26 606-106-09 Blower Wheel ......................................................................................... 1
27 618-066-00 Inner Wall ............................................................................................... 1 1
28 618-067-00 Mount, Motor .......................................................................................... 1 1
29 918-077-00 Shroud ................................................................................................... 1 1
30 618-100-00 Brace, Shroud ........................................................................................ 3 3
31 618-169-02 Insulation, Inner Wall .............................................................................. 1 1
32 618-178-00 Blower Front ........................................................................................... 1 1
33 618-181-00 Scroll ...................................................................................................... 1 1
34 618-215-00 Door, Slide Assembly ............................................................................. 1 1
35 618-095-01 Base Pan................................................................................................ 1 1
* 618-074-00 Drain Pan ............................................................................................... 1 1
* 601-799-00 Bellows, Drain Valve ............................................................................... 1 1
* 618-188-02 Grille Assembly (Rear) ........................................................................... 1 1
36 01150934 Grommet, Compressor........................................................................... 3 3
37 914-004-00 Bolt, Compressor Mounting.................................................................... 3 3
38 618-105-00 Plenum Assembly .................................................................................. 1 1
* 618-093-00 Knob, Fresh Air & Exhaust ..................................................................... 1 1
* 618-096-00 Connector, Louver .................................................................................. 2 2
* 618-097-00 Louver .................................................................................................... 20 20
* 618-097-01 Louver with Handle................................................................................. 2 2
* 618-092-00 Lever, Fresh Air & Exhaust ..................................................................... 1 1
39 618-257-02 Outer Shell Assembly (Carton with Sill Plate)......................................... 1 1
40 618-084-01 Sill Plate ................................................................................................. 1 1
41 618-104-00 Grille, Intake ........................................................................................... 1 1
* 618-199-00 Latch, Intake Grille ................................................................................. 2 2
42 602-944-10 Wingboard.............................................................................................. 1 1
* 611-050-03 Accessory Package................................................................................ 1 1
43 611-095-03 Bracket, Support .................................................................................... 2 2
44 618-197-03 Angle, Wingboard (Top).......................................................................... 1 1
45 618-198-05 Angle, Wingboard (Side) ........................................................................ 2 2
46 606-103-03 Gasket (Vinyl)......................................................................................... 1 1
* 617-173-01 Gasket (Foam) ....................................................................................... 1 1
* 608-460-16 Bag Assembly (Hardware) ..................................................................... 1 1
* Not Shown
