FC-302 Data Radio User Manual
Page 17
3 ---------priority scan, carry with tone
4.11 Channel S elect
Radio’s 16 channels can be selected by inner dip(4) switch(HW) on power board or serial command
inputted from our PC software(SW). Only in SW control mode, channel can be selected by PC software in
“Channel” feature.
5 Maintenance and Repair
5.1 Dimensions
Fig.17 Top View
Fig. 18 Exterior View
