FriFri Basic Series - Control and display elements; Basic model

CONTROL AND DISPLAY ELEMENTS
© frifri Aro SA 3-1 OM - 1.0 - 25.10.2004
3. Control and display elements
3.1 Pushbuttons, individual lamps and displays
3.1.1 “Basic” model
1 Membrane switch: “On/Off” (green LED)
2 Rotary knob: “Frying oil temperature”
3 Membrane switch: “Safety thermostat” (red LED)
4 Membrane switch: “Frying oil pump” (green LED)
5 “FMC” position (Fat Melting Cycle)
1
5
2
4
3
