5
MOUNT THE MICROWAVE
OVEN (cont.)
Installation Instructions
8
7
6
Tighten the outer two screws to the top of the
microwave oven. (While tightening screws, hold
the microwave oven in place against the wall and
the top cabinet.)
Insert 2 self-aligning screws
through outer top cabinet
holes. Turn two full turns on
each screw.
Tighten center
screw completely.
Install grease filters. See the Owner’s Manual
packed with the microwave.
C4.
22
3
2
1
Charcoal
Filter
#1 Phillips screwdriver.
Open the door.
Remove the grille.
Pull the grille straight off.
NOTE: The charcoal filter is factory installed in
recirculating models. Follow these steps to replace a
filter or to install a filter after converting a vented
model to recirculating operation.
Remove screws on top of grille using a
C5.
INSTALLING OR CHANGE
THE CHARCOAL FILTER
6
4
Replace the grille and the screws.
Close the door.
Insert
5
Install the charcoal filter: Insert filter upper
in the unit and then pull down filter. When
properly installed, the wire mesh of the filter
should be visible from the front.
To Next Page
