Installation Instructions
5
MOUNT THE MICROWAVE
OVEN (cont.)
8
7
Tighten the outer two screws to the top of the
microwave oven. (While tightening screws, hold
the microwave oven in place against the wall and
the top cabinet.)
Insert 2 self-aligning screws
through outer top cabinet
holes. Turn two full turns on
each screw.
packed with the microwave.
C4.
Tighten center
screw completely.
Install grease filters. See the Use &&&&and Care
6
C5.
INSTALLING OR CHANGE
THE CHARCOAL FILTER
(Some Models)
Unplug microwave oven or disconnect power.
1
NOTE: The charcoal filter is factory installed in some
models. Refer to the Use and Care to see if yours is
factory installed and for replacement information.
Follow these steps to replace or install a charcoal filter.
C
lose the microwave door. Plug in microwave
oven or reconnect power.
Tip forward. Lift out to
remove vent.
3
Open the microwave door and remove the two
vent mounting screws ;located on top of the
microwave using a #1 Phillips screwdriver.
2
Install the charcoal filter.
4
5
6
Reinstall the vent by sliding the bottom of the
vent into place. Push the vent top into position
and slide right into place. Replace the two vent
mounting screws located on top of the microwave
using a #1 Phillips screwdriver.
Charcoal
Filter
)NSERT
To Next Page
