3.2 Heating up the boiler
3.2.1 Switching on the system
U Switch on the main switch 9 at the control system
´ After the system check, the control system is ready
for operation
3.2.2 Switching on the boiler
Lambdatronic S3100
U Set the INDUCED DRAUGHT FAN selector switch 7.4 or
8.1 to “OFF”
U Press the START key 7.7 or 8.6
Digitronic S3100
3.2.3 Load the boiler with fuel and fire it up
U Open the insulating door and the fuel loading door
U Fill the fuel loading chamber in accordance with the
output
Use firewood with a length of approximately 50 cm and
arrange it lengthwise
The flame slot must not be obscured!
U Close the fuel loading door
U It is recommended that you do not remove the ash on the
combustion chamber during each heating-up process, to
protect the combustion chamber.
À See page 15, Removing the ash
U Open the central pre-heating chamber door
U Place some cardboard and crumpled paper under the
wood
9
8.1
8.6
7.7
7.4
