Froling FHG Turbo 3000 User Manual

Overview
Fröling Heizkessel- und Behälterbau Ges.m.b.H, Industriestraße 12, A-4710 Grieskirchen Page 5
Tel. +43 (0) 7248 606-0 Fax +43 (0) 7248 606-600 info@froeling.com www.froeling.com Edition: 23.03.2005
1
Pos. Component
1
FHG Turbo 3000 Firewood Boiler
2
Insulating door for reduced heat radiation
3
Fuel loading door
4
Pre-heating chamber door
5
Combustion chamber door
6
Side cleaning port door
7
Lambdatronic S3100 Control System
7.1
HEATING 1-4 (Auto/Off/Manual)
7.2
PUMP 1-3 (Auto/Off/Manual)
7.3
HTG 0 / OIL (Auto/Off/Manual)
7.4
BLOWER FAN (Auto/Off/Manual)
7.5
The respective LED illuminates when Pos. 7.1 – 7.4 are active
7.6
Status LED (Operating Status): - long, green blinking light: Boiler activated
- short, green blinking light: Boiler deactivated
- red blinking light: Malfunction
7.7
START key: Switch on boiler
7.8
STOP key: Switch off boiler (not possible during heating operation)
7.9
MENU keys: Manipulate the program menus
7.10
Two-line display for indicating the operating statuses
8
Digitronic S3100 Control System
8.1
INDUCED DRAUGHT UNIT (Automatic/Off/Manual)
8.2
CIRCUIT 1-2 (Automatic/Off/Manual)
8.3
Controller for adjusting: flue gas temperatures, air status, boiler temperature
8.4
3-digit display for indicating: boiler temperature, flue gas temperature, Pos. 8.3 controller
settings
8.5
Heating circuit pump (HKP) status LED: illuminates on reaching the release temperature for the
heating circuit pump
8.6
START key: Switch on boiler
8.7
STOP key: Switch off boiler (not possible during heating operation)
9
Main switch: switches the system on and off
10
STB – Safety Temperature Limiter
11
Power network fusing of the controller (glass-tube fusing 20 x 5mm 10AT)
