[ ] = Group * = Wearing parts
11
13411001.een
[A48.1306] 1 HOSE CONNECTION E6
[L2.1108] 1 AIR MOTOR D7
L2.1201 L2.1108 1 EXHAUST RING --
L2.1203 L2.1212 1 PLASTIC JACKET --
[L2.1212] L2.1108 1 HOUSING --
L2.1301 L2.1108 1 END PLATE --
L2.1302 L2.1108 1 PARALLEL PIN --
L2.1303 L2.1108 1 CYLINDER --
L2.1304
*
L2.1108 5 VANE --
L2.1305 L2.1108 1 ROTOR --
L2.1306 L2.1314 1 KEY --
L2.1308 L2.1108 1 SILENCER --
L2.1309 L2.1108 1 PLANET SHAFT --
L2.1310 L2.1108 2 NEEDLE CAGE --
L2.1311 L2.1108 2 GEAR WHEEL --
L2.1312 L2.1108 2 SHAFT --
L2.1313 L2.1108 1 BEARING RING --
[L2.1314] L2.1108 1 END PLATE --
L2.1402 L2.1108 32 BEARING NEEDLE --
L2.1403 L2.1108 2 GEAR WHEEL --
L2.1404 L2.1108 2 SHAFT --
L2.1405 L2.1108 1 BEARING RING --
L2.1408 L2.1108 1 PLANETARY CAGE --
L2.1409 L2.1413 1 AIR INLET RING --
L2.1410 L2.1413 1 TENSION SCREW --
L2.1411 L2.1413 1 THROTTLE HEAD --
L2.1412 L2.1413 1 THROTTLE SCREW --
[L2.1413] L2.1108 1 AIR INLET HEAD --
L2.1505 L2.1108 1 KEY --
N1.1110 2 SCREW M5 X 8 D3
N1.1125 2 SCREW M6 X 16 A3+
N1.1125 A48.1301 2 SCREW M6 X 16 A3
N1.1143 1 SCREW M6 X 35 B4
N1.1168 2 SCREW M5 X 16 E1
N1.1170 2 SCREW M6 X 35 C1
N1.1202 2 SCREW M5 X 10 B3
N1.1208 A48.0113 2 SCREW M5 X 25 C3
N1.1539 1 HEXAGON SCREW M5 X 14 D4
N1.2105 A48.0113 1 COUNTERSUNK SCREW M5 X 25 D2
N1.2135 2 COUNTERSUNK SCREW M5 X 12 D3+
N1.2136 1 COUNTERSUNK SCREW M5 X 8 E4
N1.2209 2 COUNTERSUNK SCREW M4 X 18 B5
N1.5103 1 HEXAGON NUT M5 D4
N1.5301 1 RETAINING NUT M6 A4
N1.5302 A48.0113 3 RETAINING NUT M5 C1
N1.6207 2 SPRING LOCK WASHER M5 B3+
N1.6207 A48.0113 2 SPRING LOCK WASHER M5 C3
N1.6701 L2.1108 2 TOOTH LOCK WASHER --
N2.2102 1 PARALLEL PIN 5 m6 X 16 D3
N2.2102 A48.1134 2 PARALLEL PIN 5 m6 X 16 D3
N2.2106 2 PARALLEL PIN 5 m6 X 20 E2
N2.2129 A48.1134 2 PARALLEL PIN 5 m6 X 10 D3
N2.3201 2 WOODRUFF KEY 4 X 6.5 X 15.72 D3+
13.4110.01 A480/19/0.38-0.63/4.5 A480.0001.01 11.06.02
Item-No. in group Pcs. Description Dimension Field
