Fromm A480 - Page 12

[ ] = Group * = Wearing parts
12
13411001.een
N2.4902 2 HAMMER HEAD BOLT 1.85 X 4.76 C2
N2.5102 2 PRESSURE SPRING 0.6 X 8 X 14/6 C4+
N2.5131 1 PRESSURE SPRING 0.5 X 6 X 15/7.5 C4
N2.5144 1 PRESSURE SPRING 3 X 54 X 125/6.5 C4
N2.5145 1 PRESSURE SPRING 2.8 X 36 X 55/5 A2
N2.5151 1 PRESSURE SPRING 0.3 X 2.8 X 11/11.5 C5
N2.5802 1 BENDING SPRING 2.5 X 11.5/3.25 C4
N3.1102 L2.1108 4 BALL BEARING 15 X 32 X 9 --
N3.1108 L2.1108 1 BALL BEARING 6 X 19 X 6 --
N3.1109 L2.1108 1 BALL BEARING 8 X 22 X 7 --
N3.1131 1 BALL BEARING 12 X 32 X 10 D6
N3.1708 2 BALL 10 MM C4+
N3.2312 1 NEEDLE BUSH 15 X 21 X 14 D3
N3.2313 1 NEEDLE CASE 12 X 18 X 12 C4
N3.2314 1 NEEDLE CASE 15 X 21 X 12 C6
N3.2314 A48.1244 1 NEEDLE CASE 15 X 21 X 12 E2
N3.4102 1 THRUST BEARING CAGE 15 X 28 X 2 C5
N3.4307 2 THRUST RACE 15 X 28 X 1 D5
N41.9128 1 ADHESIVE LABEL 30 X 10 X 0.1 A4
N41.9129 1 ADHESIVE LABEL p max. 6 bar/87 psi A4
N4.9135 1 NUMBER PLATE <<A480>> B2
N6.5133 1 REDUCING COUPLING D5
N6.5195 2 FITTING A4+
N6.6229 4 O-RING 14 X 1 C4
N6.6230 2 O-RING 8 X 1.5 C4+
N6.6234 L2.1413 1 O-RING 7.1 X 1.6 --
N6.6505 L2.1413 1 FLAT SEAL 21 X 17 X 1,5 --
N6.6701 1 DIAPHRAGM B4
N7.1101 A48.1244 1 BUSH 10 X 15 X 10 D2
N7.1201 A48.1244 1 SEALING DISK 16 E2
13.4110.01 A480/19/0.38-0.63/4.5 A480.0001.01 11.06.02
Item-No. in group Pcs. Description Dimension Field
