Fromm P331 M - Page 16

1-22
P33.2102/
N31.3111
F15
P33.2102/
N3.3189
F16
P32.1022/
N3.1134/
P33.2104
F17
Part Disassembly Assembly
N72.3216
N7.3235
N72.3217
N31.3111
P33.2102
*Pay attention to the
direction of the joint
see assembly information
N71.3250
N7.3235
N71.3251
N3.3189
P33.2102
*Pay attention to the
direction of the joint
see assembly information
N72.3219
N71.3244
P33.2104
N3.1134
P32.1022
N71.3243
