SERVICE MANUAL
BATTERY - POWERED
PLASTIC STRAPPING TOOL
MODEL
P328 M/HA / P328 A/A
P328.sen.fm/MAS/© 02.16
Manual for authorized dealers and service points
Purchase at Allstrap (866) 779-2673

Table of Contents

Questions and Answers

  • G
    George ArellanoAug 3, 2025
    How to troubleshoot a Fromm P328 M that doesn’t work at all?
    • S
      Scott KelleyAug 3, 2025
      If your Fromm Packaging equipment isn't working, there could be several reasons: * The battery might be empty or defective, in which case you should charge or replace it. * There could be contact problems due to a broken battery housing, requiring battery replacement. * Damaged parts like insertation part N51.2194 or motor housings P32.8103 and P32.8105/96 could cause contact issues, necessitating their replacement. * Internal wire contact problems may exist, requiring contact checks and fixes or defective part replacements. * A defective circuit board might be the cause, requiring its replacement.
  • A
    Amanda BarnesAug 23, 2025
    Why does the tensioning wheel turn back immediately after tensioning cycle in Fromm P328 M Packaging equipment?
    • B
      Brandy DuncanAug 23, 2025
      If the tensioning wheel on your Fromm Packaging equipment turns back immediately after the tensioning cycle, it might be due to a defective needle free wheeling N3.4509 in P32.8134. Check these parts and replace them if necessary.
  • S
    solomontheresaNov 11, 2025
    What to do if Fromm Packaging equipment doesn’t tension?
    • K
      kathleen58Nov 11, 2025
      If your Fromm Packaging equipment isn't tensioning, it could be due to the following reasons: * The tensioning wheel might be dirty or worn. Try cleaning it, or replace it if necessary. Avoid using hard objects. * P32.8128 might not be meshing with P32.8130 because spring N2.5296 is defective or parts are dirty. Replace the spring and clean the parts. * The tensioning wheel could be faulty or assembled incorrectly. Ensure it's assembled correctly. * The grippers might be dirty, worn, or wrongly assembled. Replace or clean the grippers, or assemble them correctly, avoiding hard objects. * The gearing parts from the tensioning gear could be defective. Check the tensioning gear and replace any defective parts. * A defective circuit board might be the cause. Replace the circuit bo...

Summary

1.1 ACCESSORIES

1.1.1 Battery

Information on original Fromm Li-Ion batteries.

1.1.2 Battery chargers

Details on ordering battery chargers for specific countries.

1.1.3 Battery tester

Information source for the battery tester.

1.1.4 Memory reader for circuit board

Describes the N7.5154 reader and its capabilities.

1.1.5 Suspension

How to suspend the strapping tool using brackets.

1.1.6 Fan

Recommendation for using the optional fan P32.0228.

1.2 TECHNICAL DETAILS

1.2.1 Strap tension

Factors affecting strap tension achievability.

1.2.2 Electric schematic Semi Automatic ELS.1082

Electrical diagram for the Semi Automatic ELS.1082 model.

1.2.3 Connecting plan Semi Automatic

Wiring diagram for the Semi Automatic model.

1.2.4 Electric schematic Automatic ELS.1083

Electrical diagram for the Automatic ELS.1083 model.

1.2.5 Connecting plan Automatic

Wiring diagram for the Automatic model.

1.3 CONVERSION PARTS P328

1.4 PERIODIC MAINTENANCE AND CONTROL

1.4.1 Procedure

Steps for checking and maintaining the tool.

1.4.2 Troubleshooting

Common issues and their solutions for the tool.

1.4.3 Battery test

How to check battery health during maintenance.

1.4.4 Checklist

A list of checks to perform during test strappings.

1.4.5 Lubrication rules

Guidelines for lubricating gear parts and bearings.

1.4.6 Glueing rules

Instructions for gluing specific parts using adhesives.

1.4.7 Assembly information

Details on proper assembly of components like bearings and grippers.

1.5 RECOMMENDED SPARE PARTS

1.6 MAINTENANCE PLAN P328

1.7 ACCESSORY TOOLS

1.8 USE OF ACCESSORY TOOLS

Part F1

Disassembly and assembly for accessory tool F1.

Part F2

Disassembly and assembly for accessory tool F2.

Part F3

Disassembly and assembly for accessory tool F3.

Part F4

Disassembly and assembly for accessory tool F4.

Part F5

Disassembly and assembly for accessory tool F5.

Part F6

Disassembly and assembly for accessory tool F6.

Part F7

Disassembly and assembly for accessory tool F7.

Part F8

Disassembly and assembly for accessory tool F8.

Part F9

Disassembly and assembly for accessory tool F9.

Part F10

Disassembly and assembly for accessory tool F10.

Part F11

Disassembly and assembly for accessory tool F11.

Part F12

Disassembly and assembly for accessory tool F12.

Part F13

Disassembly and assembly for accessory tool F13.

Part F14

Disassembly and assembly for accessory tool F14.

Part F15

Disassembly and assembly for accessory tool F15.

1.9 ORDERING SPARE PARTS

1.9.1 Ordering manuals

Procedures for ordering manuals for tool conversions.

1.9.2 Ordering address

Contact information for ordering spare parts and manuals.

1.9.3 Finding out of the tool type (item number), the serial number and the version number

How to identify tool type, serial, and version numbers.

1.10 SERVICE ADDRESS

1.11 CHART OF TYPES

1.11.1 Chart of types P328 M; HA

Table of available P328 M/HA models and specifications.

1.11.2 Chart of types P328 A; A

Table of available P328 A/A models and specifications.
