[ ] = Group * = Wearing parts
3-3
[P33.0206] P33.0208 1 LEVER C16
[P33.0207] P33.0208 1 GEAR BODY B17
[P33.0208] P33.0212/13 1 GEAR B14+
[P33.0209] P33.0212/13 1 CONICAL GEAR WHEEL D23
[P33.0210] P33.0212/13 1 GEAR WHEEL C22
P33.0211 * P33.0212/13 1 MOTOR D22
P33.2102 P33.0201 1 BODY D7
P33.2103 P33.0201 1 BOLT A18
P33.2104 P33.0202 1 PINION A15
P33.2105 P33.0203 1 SPRING BOLT B8
P33.2106 P33.0203 1 SPRING SLIDE A8
P33.2107 P33.0212/13 1 RETAINER A23
P33.2108 P33.0205 1 GEARING COVER D15
P33.2109 P33.0207 1 GEAR BODY B16
[P33.2111] P33.0212/13 1 MOTOR HOUSING A22
P33.2115 P33.2116/38 1 TURNING BUTTON C20
P33.2117 P33.0212/13 1 HANDLE LEVER B21
P33.2122 P33.0209 1 CONICAL GEAR WHEEL D23
P33.2123 P33.0210 1 GEAR WHEEL C21
P33.2124 P33.0212/13 1 CONICAL GEAR WHEEL C22
P33.2130 P33.0212/13 1 ECCENTRIC SHAFT C9
P33.2131 P33.0212/13 1 GEAR WHEEL A23
P33.2132 P33.0212/13 1 COVER B9
P33.2133 P33.0212/13 1 PUSHER B14
P33.2135 P33.0212/13 1 INSERTATION PART A20
P33.2136 P33.0212/13 1 COVER A20
P33.2137 P33.0212/13 1 HANDLE SHAFT C19
P33.2142 1 CENTERING SLEEVE C12
P33.2143 1 COVER A4
P33.2145 P33.0212/13 1 DISK B22
P33.2155 P33.0212/13 1 DOWEL C22
[P35.0202] P33.0212/13 1 ROCKER A15
[P35.0213] P33.0208 1 GEAR WHEEL B15
[P35.0214] P33.0208 1 WHEEL C13
[P35.0217] P33.0208 1 RATCHET WHEEL C17
[P35.0218] P33.0208 1 GEAR WHEEL D16
[P35.0226] 1 END COVER D4
[P35.0227] 1 PUSHER B12
P35.4104 * 1 WELDING STOP GRIPPER D9
P35.4105 1 STRAP GUIDE PLATE A3
P35.4106 P35.0202 1 ROCKER A16
P35.4107 * P33.0212/13 1 WELDING GRIPPER D10
P35.4110 P33.0212/13 1 DRIVING PIN C11
P35.4111 P33.0212/13 2 DRIVER D10+
P35.4150 P35.0213 1 GEAR WHEEL B15
P35.4151 P35.0214 1 GEAR WHEEL C13
P35.4154 P35.0214 1 PLANET SHAFT C14
P35.4155 P35.0214 3 PINION C13
P35.4156 P33.0206 1 LEVER C16
P35.4159 P35.0217 1 GEAR WHEEL C17
P35.4160 P35.0218 1 GEAR WHEEL D16
P35.4184 1 HOLDER C3
P35.4196 3 PINION B4
P35.4197 P35.0226 1 END COVER D4
Item-No. in group Pcs. Description Dimension Field
