Fromm P404 - Page 11

[ ] = Group * = Wearing Parts
11
[P40.0104] 1 BASE PLATE E3
P40.2004 1 TENSION SHAFT B5
P40.2012 1 HOLDING-DOWN CLAMP E3
P40.2017 1 ROD BAR A2
P40.2018 1 BUSH A2
P40.2024 1 SHAFT C7
P40.2025 1 LEVER C6
P40.2028 1 HINGE C5
P40.2029 2 SPLIT-PIN BOLT B5+
P40.2030 1 SHAFT B5
P40.2045 1 SCREW E4
P40.2052 2 LINER D5
P40.2053
*
1 GRIPPER D5
[P40.2501] P40.0101 1 HOUSING C3
P40.2503 P40.0102 1 PUNCH SUPPORT D2
P40.2504 1 PILLAR C1
P40.2505 1 SHIM 0,2 MM D3
P40.2506 1 SHIM 0,3 MM D3
P40.2507 1 PAWL E2
P40.2508
*
1 PUNCH E2
P40.2509 2 SHAFT E2+
P40.2510 1 PRESSURE ROLLER D1
P40.2511 1 STOP C3
P40.2512 2 GUIDE GIB D5
P40.2513 1 SEALING CAM B3
P40.2514 1 SEALING HANDLE A4
P40.2515 1 DOWEL C2
P40.2516 1 SHAFT C2
P40.2517 1 COVER C2
P40.2518 1 TENSION HANDLE B4
P40.2519 1 SIDE PLATE D5
P40.2520 1 CLAMPING LEVER C7
P40.2521
*
1 GRIPPING JAW D6
P40.2522 1 GRIPPING JAW PIN D6
P40.2523 1 STOP D3
P40.2524
*
1 SHEAR BLADE D4
P40.2525
*
1 SHEAR BLADE D4
P40.2526 1 BOLT D3
P40.2527 1 TENSIONIG DRUM D6
P40.2528 P40.0103 1 ROCKER B6
P40.2529 P40.0104 1 BASE PLATE E3
43.0404.02 P404/15-16/0.50-0.90 P404.0001.02 12.01.00
Item-No. in group Pcs. description Dimension Field
