Fromm P404 - Spare Parts List 43.0404.02

[ ] = Group * = Wearing Parts
10
6 SPARE PARTS LIST 43.0404.02
43.0404.02 P404/15-16/0.50-0.90 P404.0001.02 12.01.00
Item-No. in group Pcs. description Dimension Field
A33.3111 2 CATCH PAWL B4
A43.1207 2 DISK B4+
N11.1154 2 SCREW M10 X 97 B3
N1.1125 3 SCREW M6 X 16 E4
N1.1162 2 SCREW M3 X 12 E2
N1.1909 1 FLAT HEAD SCREW M3 X 5 E5
N1.1910 4 FLAT HEAD SCREW M4 X 12 E6
N1.2104 1 COUNTERSUNK SCREW M4 X 12 D3
N1.3106 1 SOCKET SET SCREW M5 X 6 B5
N1.3508 1 SOCKET SET SCREW M5 X 20 B6
N1.3511 1 SOCKET SET SCREW M4 X 10 C2
N1.5131 1 HEXAGON NUT M5 B6
N1.6203 1 SPRING LOCK WASHER M3 E5
N1.6226 2 SPRING LOCK WASHER M10 C4
N1.6504 5 SAFETY WASHER M4 D5+
N2.1122 1 SECURITY RING E21 B4
N2.1128 1 SECURITY RING E4 A2
N2.1609 1 SPRING RING 10 MM C1
N2.2185 2 PARALLEL PIN 6 m6 X 32 C4+
N2.2441 4 DOWEL PIN 6 X 20 MM A3+
N2.2447 1 DOWEL PIN 2 X 4 MM E2
N2.2457 1 DOWEL PIN 5 X 28 C6
N2.2709 2 SPLIT PIN 1,6 X 10 MM B5+
N2.2806 1 DOWEL PIN 5 X 16 MM C7
N2.2816 2 DOWEL PIN 4 X 10 MM E3
N2.4902 3 HAMMER HEAD BOLT 1.85 X 4.76 D4+
N2.5154 2 PRESSURE SPRING 0.45 X 3.9 X 7 B4
N2.5211 1 PRESSURE SPRING 1,2X13X92,7/17.5 B2
N2.5212 2 PRESSURE SPRING 0,4X3,6X18,3/14.5 E2
N2.5234 1 PRESSURE SPRING 0.56 X 4.25 X 77.50 /
28.5
C1
N2.5614 3 CUP SPRING 10X4,2X0,6 D3
N2.5819 1 TORSION SPRING 2,2/22,8 C6
N2.5820 1 TORSION SPRING 1 / 9 D2
N3.2609 P40.0101 2 PACKING RING C5+
N3.3113 P40.0103 2 SLIDE-BEARING B5+
N3.3148 P40.0101 1 SLIDE-BEARING C3
N3.3150 P40.0101 1 SLIDE-BEARING B2
N3.3151 P40.0101 2 HEADED PRESS FIT BUSH C6
N3.3167 P40.0104 1 SLIDE-BEARING 10 X 12 X 15 D3
N3.3171 P40.0101 2 SLIDE-BEARING D4
N3.3171 P40.0102 2 SLIDE-BEARING D3
N3.4506 P40.0101 1 NEEDLE FREE WHEELING D5
N41.9110 1 TYPE PLATE <<P404>> D6
N41.9127 1 ADHESIVE LABEL E6
N4.1116 2 GRIP BALL A5
N4.5120 1 PROTECTION PLUG C4
N7.1207 P40.0101 1 SEALING DISK D1=14MM C3
[P40.0101] 1 HOUSING C3
[P40.0102] 1 PUNCH SUPPORT D2
[P40.0103] 1 ROCKER B6
