1 SAFETY INSTRUCTIONS
Read these instructions carefully. Failure to follow these instructions can result in severe personal injury.
Eye injury hazard
Failure to wear safety glasses with side shields can result in severe eye injury or blindness.
Always wear safety glasses with side shields which conform to ANSI Standard Z87.1.
Operation
Tool must not be used by persons not properly trained in their use. Before tensioning strap, read and
understand the tool operating instructions. Failure to follow the operating instructions or improperload
positioning could result in strap breakage.
Become familiar with your tool and keep fingers away from areas that can pinch or cut.
Cutting tensioned strap
When cutting strapping, use the proper strapping cutter and keep other personnel and yourself at a safe
distance from the strap. Always stand to side of the strap, away from the direction the loosened strap end will
fly. Use only cutters designed for strap and never hammers, pliers, hacksaws, axes, etc.
INDEX PAGE
1 SAFETY INSTRUCTIONS 2
2 TECHNICAL DATA 3
3 OPERATION ELEMENTS 4
4 ADJUSTMENT OF THE STRAP THICKNESS 5
5OPERATION 5
6 SPARE PARTS LIST 43.0404.02 10
7 EXCHANGE OF WEARING PARTS 12
7.1 Exchange of the cutter . . . . . . . . . . . . . . . . . . . . 12
7.2 Exchange of gripper and gripping jaw . . . . . . . . 13
8 WARRANTY CONDITIONS AND LIABILITY 14
9 APPROPRIATE USE 14
