Fronius Primo 3.0-1 Quick Start Guide

DC= (+) DC= (-)
DC= (+) DC= (-)
~ 20 mm~ 20 mm
DC= (+) DC= (-)
DC= (+) DC= (-)
1122
Torque (Nm / lbf.in.)
→ see printing near
wire terminal
2x TX20
1,5 - 1,7 Nm
min. 2,5 mm² - max. 16 mm²
DC= (+)
DC= (-)
MPPT1
MPPT2
2x TX20
7 x 2,5 - 10 mm²
2 x 10 - 16 mm²
D1
D2
D3
D1
D1
D1
15 mm
70 mm
D > 6 mm
2423
DC=
22
30
29
28
272625
33
32
31

Fronius Primo 3.0-1 Specifications

General

Purpose	Solar panel
Efficiency	98 %
Output power	3000 W
Input current	12 A
Input voltage	80 - 1000 V
Output voltage	- V
Input frequency	50 - 60 Hz
Power supply type	Auto
Adjustable output voltage	-
International Protection (IP) code	IP65
Product color	Black, Grey
Built-in display	Yes
Operating temperature (T-T)	-40 - 55 °C

Weight and Dimensions

Depth	204 mm
Width	431 mm
Height	645 mm
Weight	21500 g
