Fronius Symo 12.5-3-M User Manual

9
EN
Copyright
Copyright of these operating instructions remains with the manufacturer.
The text and illustrations are all technically correct at the time of printing. We
reserve the right to make changes. The contents of the operating instructions
shall not provide the basis for any claims whatsoever on the part of the pur-
chaser. If you have any suggestions for improvement, or can point out any
mistakes that you have found in the instructions, we will be most grateful for
your comments.

Fronius Symo 12.5-3-M Specifications

General

Dimensions	725 x 510 x 225 mm
Protection class	IP 66
Topology	Transformerless
Operating temperature range	-25°C to +60°C
Max. output current	18.1 A
THD	< 3%
Number of MPP trackers	2
Maximum Input Voltage	1000 V
Warranty	5 years
AC nominal output	12500 W
Max. apparent AC power	12500 VA
DC input voltage range	200 V - 1000 V
MPP voltage range	200 V - 800 V
AC nominal voltage	3 x 230 / 400 V
