The Setup menu
Setting options
Welding process Settable parameters Factory setting
Arc-force dynamic Level 2
Arc-force dynamic Level 2
Cel characteristic and arc-force dynamic Level 2
TIG Comfort Stop Level 0
Pulse frequency (TP 2500/3500 TIG only) Level 1
Functional prin-
ciple
The parameters can be set at 4 levels (TP 2500/3500) or 5 levels (TP 2500/3500 TIG).
The number of indicators lit corresponds to the level reached.
Level 0 Level 1 Level 2 Level 3 Level 4 Level 5
Setting paramet-
ers
To alter a parameter setting, proceed as follows:
1. Using the "Process" button, select the desired parameter and hold the Process but-
ton down.
- the set level is indicated for 1 second
- while the Process button is held down, the set value is raised one level every
second
2. Release the process button once the desired level is set.
3. The setting is now saved
4. The set process is displayed
IMPORTANT! The welding parameters are retained even if the mains plug is dis-
connected.
