(4) Select the process:
- AC welding
- DC- welding
- DC+ welding (only with rod electrode)
(5) Final current
(6) Main current controller
(7) DownSlope or current lowering time
MagicWave con-
trol panel
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(23)
(22)
(18)
(17)
(16)
(15)
(14)
(13)
(12)
(11)
(10)
(9)
(8)
(19) (21)
(20)
Fig.5 Control panel for MagicWave 2600 / 2600 CEL / 3000
(1) Welding current indicator ... for displaying the main current I
H
- Set value ... desired welding current
- Actual value ... actual welding current
(2) Welding voltage indicator
- for displaying the current actual value of the welding voltage
(3) Mode button
(4) Manual metal arc welding
Manual metal arc welding symbol
(5) Contact ignition, can only be combined with TIG 2-step mode, or TIG 4-step
mode
Contact ignition symbol
(6) 4-step mode ... TIG welding with HF ignition
4-step mode symbol
22
