14
N.B.! Insert the pressure and drive rollers in such a way that you can still
see and read the designation for the wire diameter.
- Insert the axle
again - the anti-twist lock of the axle must latch into
place
- Push the pressure lever downwards
- Pull the clamping device
into the vertical position
- Replace the left side panel of the power source / housing of the
wirefeeder
CORRECTING THE WIRE INFEED
For smooth wirefeed, the wire electrode must run into the torch without
abrading.
The wire infeed is factory-adjusted to optimum settings. However, it may
be necessary to make minor corrections after individual components
such as wirefeed rollers, the drive motor etc. have been changed. The
wire infeed can then be “fine-tuned” by slightly loosening the Allen screws
.
