Fronius VR 1500-PAP - Connection Ports

Connections
(3)
(1)
(6)
(5)
(4)
(2)
(7)
(8)
Connections on the front
(1) Blanking cover or for optional
blow-off
(2) Torch shielding gas connection
(3) Gas pressure sensor VR 1500 op-
tion or Digital Gas Control option
(4) Torch CAT lead connection
(5) Shielding gas input connection
(6) Control line connection
(7) Welding potential connection from
the hosepack extension for gas-
cooled applications
(8) Welding torch connection
