19
4
5
6
6
6
6
7
8
9
12
13
14
15
15
14
12
13
21
22
16
17
19
20
22
21
16
17
18
19
20
10
3
2
1
WC1208 Feed Carriage Assembly
Ref# Description Part#
1 Lock Nut, 3/8 5PQ003000
2 Flat Washer, 3/8 5PQ001035
3 Feed Carriage Weldment 5PQ903065
4 Bolt, 1/4 x 6 5PQ000212
5 Flat Washer, 1/4 5PQ001020
6 Coupling Shield 5PQ903495
7 Lock Washer, 1/4 5PQ000805
8 Nut, 1/4 5PQ000900
9 Rubber Block 5PQ505269
10 Bolt, 3/8 x 1-1/2 5PQ000280
12 Hydraulic Fitting 5PQ900190
13 Hydraulic Motor 5PQ900178
14 Key, 1/4 x 1 5PQ400114
15 Coupling Chain 5PQ903490
16 1-1/2" Flange Bearing 5PQ400810
17 Key, 3/8 x 1-1/2 5PQ401580
18 Feed Roller 5PQ903027
19 Machinery Bushing, 1/2 5PQ000530
20 Bolt, 1/2 x 1 5PQ000405
21 Nut, 1/2 5PQ000940
22 Bolt, 1/42 x 1-3/4 5PQ000445
23 1" Coupling Sprocket 5PQ903056
24 1-1/2" Coupling Sprocket 5PQ903057
