Frontier WC1208 - Chute Assembly

21
WC1208 Chute Assembly
1
2
3
4
5
6
7
8
9
10
Ref# Description Part#
1 Set Bolt 5PQ500148
2 Bolt, 3/8 x 1-1/2 5PQ000280
3 Chip Chute 5PQ903486
4 Chip Deector 5PQ903197
5 Bolt, 3/8 x 7/8 5PQ000250
6 Flat Washer, 3/8 5PQ001035
7 Locknut, 3/8 5PQ003000
8 Clamp Handle 5PQ806039
9 Locknut, 3/8 5PQ003000
10 Chute Retainer 5PQ903487
