FIGURE 2
FRONTIER MODEL WR3010 & WR3012
OPTIONAL KICKER WHEEL
ITEM WR3010 WR3012 DESCRIPTION
1. 5HP10WR41 “ Kicker Arm
2. 5HP10WR39 “ Mounting Bracket Top
3. 5HP10WR20 “ Mount
4. 5HP10WR19 “ Pulley Mount
5. HPBFR292 “ Poly Pulley
6. HPST81 “ Spacer
7. 5HP10WR40 “ Pivot Mount
8. 5HP10WR18 “ 5/16”x3” Bolt GR.5
9. 5HPF87 “ “S” Hook
10. HPES14 “ Cable Protector
11. HPES5 “ Crimp On Clamp
12. 5HP12WR6 “ Cable (57”)
13. 5HPT19 “ 3/8” x 2” Bolt GR.5
14. HPES10 “ I-Bolt (5/16” x 4” Overall)
15. HPBFR110 “ Spring
16. HPT163 “ Seal
17. HPT164 “ Inner Bearing
18. HPT165 “ Inner Race
19. HPT168 “ Hub Bolt
20. HPBFR32 “ Hub
21. HPT166 “ Hub Nut
22. HPT171 “ Outer Race
23. HPT170 “ Outer Bearing
24. HPT172 “ Nut
25. HPT169 “ Cotter Pin
26. HPT173 “ Hub Cap
27. 5HP10WR17 “ 48” Kicker Wheel
28. HPT179 “ Rake Wheel Center
29. HPT178 “ Rake Tooth Clip
30. 5HP10WR42 “ Rake Wheel Tooth
31. HPT168 “ 10mmx25mm Bolt
32. HPT166 “ 10mm Lock Nut
33. HP3G22 “ Roll Pin
34. HP12V45 “ 1/2”x1-1/2” Bolt GR.5
35. HPS99 “ “O” Ring
36. HPG16 “ Bronze Bushing
37. HPBFR230 “ Bearing Spacer
38. HPBFR221 “ Poly Washer
39. 5HP10WR44 “ Chain (5 Links)
40. HPBFR295 “ Snap Hook
41. 5HP10WR43 “ 3/8”x1” Bolt
42. HPBFR229 “ Washer
43. HPT177 “ Outer Ring
NOTE: “ (MEANS SAME AS PREVIOUS PART NO.)
-25-
