12
Appendix C
Reboot & Shutdown
To reboot or shut down the server (for relocation or troubleshooting), go to the System/Bootup and Shutdown menu and
select the desired option at the bottom of the page. Turning off the DRS5000 by holding the power button on the front is
not recommended and should only be used as a last resort.
Appendix D
Advanced IP Setup
This is the process for reaching the server and devices from a client computer that falls outside of the defined subnet range.
Note that this does not include audio over IP packets sent/received from Conductor. Conductor is limited to the DRS5000’s
IP address subnet.
This setup procedure, although not used often, allows the Maestro client to connect to the server database from outside the
school’s local network.
1. Log into Webmin on the DRS5000
2. In the left menu click on Servers to open list
3. Click on PostgreSQL Database Server
4. On the right, click on Allowed Hosts under User, Groups and Permissions
5. At the bottom of the allowed hosts list, click on Create a new allowed host
6. If the remote client station is external and connecting via the internet, then:
• Click on the radio button for the Single Host line
• Fill in the FULL IP address for the client host
7. If the remote client station is connecting via the school LAN or WAN but is outside the subnet for the DRS5000, AND
if the network of the remote client is not already listed as an Allowed Host, AND if that network does NOT start with
10.x.x.x or 172.16-31.x.x or 192.168.x.x, and, if you want to allow Conductor or Maestro access from ANY host on
the new network: (the next three lines apply)
• Click on the radio button for the Network line with CIDR length line
• Fill in the first 3 octets of the client’s address followed by a 0, (e.g. 164.42.2.0)
• Enter 24 for the CIDR length
If you want only ONE client station to be able to access Conductor or Maestro:
• Click on the radio button for Single host
• Fill in Single host text field with that client’s address
8. For the Authentication mode, click on the MD5 encrypted password radio button
9. Click Create
