2-6
Item
Part #
GF40 Frypot Components
1 806-5567
Flue
2 823-6667
Frypot
3 826-1177
Hi-limit
thermo
stat
* 807-1692
Operating
therm
ostat
* 810-1569
Valve,
1.25-inch
Dr
ain
* 910-3557
Deflector,
flue
* 826-0861
Insulation
kit
21
23
