Electric Fryers
3-7
14-17kW Mechanical 50
amp heating contactor.
(5-10 ohms coil). Used on
domestic units after April 08
until June 2017.
22kW Mechanical 63 amp
heating contactor. (3-7 ohms
coil). This contactor replaced
mercury contactors on
domestic fryers in April 08 until
June 2017.
A new heat contactor, introduced in
June 2017, ships in a kit with a bracket
(shown). It has a different footprint.
Color Description
RED 435°F (218°C) - used on 22kW FV & DV
, 17kW DV, 14kW DV
BLACK 425°F (224°C) - used on 17kW FV, 14kW FV
Hi-Limits
Hi-limits are color coded
at the base for easy
identifi cation. See the
following table for the color-
code and part description.
The temp probe and hi-limit are visible in an electric frypot.
Black and red color-coded
hi-limits.
Hi-limit
Probe
