2-7
3. For fryers equipped with casters, there are no built-in leveling devices. The floor where the
fryer is to be installed must be level.
4. Test the fryer electrical system: Verify correct voltage and connect per National codes and
regulations.
a. Plug the fryer electrical cord(s) into a grounded electrical receptacle.
b. Place the power switch in the ON position.
For fryers equipped with thermostat controls, verify that the power and heat lights are
lit.
For fryers having computer or digital displays, verify that the display indicates
CYCL..
c. Place the fryer power switch in the OFF position. Verify that the power and heat lights are
out, or that the display is blank.
5. Refer to the data plate on the inside of the fryer door to verify that the fryer burner is
configured for the proper type of gas before connecting the gas line quick-disconnect device or
piping from the gas supply line.
6. Verify the minimum and maximum gas supply pressures for the type of
gas to be used in accordance with the accompanying tables:
7. For fryers equipped with a built-in filter system and/or basket lifts, plug
the electrical cord(s) into a power receptacle behind the fryer.
CE Standard for Gas Pressure
Model 50
Gas Type G20 G25 G30 G31
Rate (kW NET) 28.5
Pressure (mbar) 20 20-25 37-50 37-50
Orifice Size (mm) 1.40 1.40 0.86 0.86
Number of Orifices 18 18 18 18
Manifold Pressure (mbar) 7,5 10 20,6 20,6
Non- CE Standard for Gas Pressure
Model 40/GF16FR Model 50
Gas Type Nat LP Nat LP
Min Pressure W.C/kpa/mbar 6/1.49/14.93 11/2.74/27.37 6/1.49/14.93 11/2.74/27.37
Max Pressure W.C/kpa/mbar 14/3.48/34.84 14/3.48/34.84 14/3.48/34.84 14/3.48/34.84
Orifice Size (mm) 1.7 1.05 1.45 0.86
Number of Orifices 9 9 18 18
Manifold Pressure (WC) 4 10 3.0 8.25
Australian Standard for Gas Pressure
Model 40/GF16FR/AGF14 Model 50
Gas Type Nat LP Nat LP
Min Pressure 1.13kpa 2.75 kpa 1.13kpa 2.75 kpa
Max Pressure 5.0 kpa 7.0 kpa 5.0 kpa 7.0 kpa
Orifice Size (mm) 1.7 1.05 1.20 0.81
Number of Orifices 9 9 18 18
Manifold Pressure 0.80 kpa 2. 5 kpa 0.96 kpa 2.2 kpa
NOTE: Gas
specifications are
included on appliance
data plate located
inside the door.
