2-9
Performance Series Atmospheric gas fryers have
received the CE mark for the countries and gas
categories indicated in Table 3 (right).
The size of the gas line used for installation is
very important. If the line is too small, the
gas pressure at the burner manifold will be
low. This may cause slow recovery and
delayed ignition. The incoming gas supply
line should be a minimum of 1½" (38 mm) in
diameter. Refer to the Table 4 (right) for the
minimum sizes of connection piping.
CE Standard
CE regulations require a combustion air supply of 2m
3
/h per kW per fryer. (See rating
plate affixed to door for kW rating.)
1. Connect the quick-disconnect hose to the fryer quick-disconnect fitting under the front of the
fryer and to the building gas line. The gas inlet connection will be up to 1.5” NPT (38.1mm),
depending on the number of fryers in the battery. The gas connection point will be about 13”
(326mm) from the floor. The left-to-right position will vary according to the number of fryers in
the battery.
SOUTH AFRICA REQUIREMENT (LPG FRYERS ONLY)
This appliance requires an operating pressure of 2,8 kPa at the appliance. A suitable LPG regulator
that complies with the requirements of SANS 1237 must be installed.
BE
I2E+(S)
I3P
G20/G25
G31
20/25
37
DE
I2 ELL
13P
G20/G25
G31
20
50
FR
II2Esi3P
G20/G25
G31
20/25
37 ET 50
LU
I2E G20/G25 20/25
ES
II2H3P
G20
G31
20
37 ET 50
NL
II2L3P
G25
G31
25
50
IE-PT-GB
II2H3P
G20
G31
20
37
DK-GR-IT
I2 H G20 20
Table 3: CE Approved Gas Categories
Country Category Gas
Pressure
(mbar)
Table 4: Gas Connection Pipe Sizes
(Minimum incoming pipe size should be 1-1/2" (38 mm))
Natural 3/4" (19 mm) 1" (25 mm) 1-1/4" (33 mm)
Propane 1/2" (13 mm) 3/4" (19 mm) 1" (25 mm)
* For distances of more than 20 feet (6 meters)
and/or more than four fittings or elbows, increase
the connection by one pipe size.
Gas Single Unit 2 - 3 Units 4 Units*
