Conguring the Switch Using the Console Port
Step 3: Open a browser, type http://192.168.1.1 and enter the default username and password,
admin/admin.
Step 4: Click Login to display the web-based conguration page.
Step 1: Connect a computer to the console port of the switch with the console cable.
Step 2: Start the terminal simulation software, such as HyperTerminal on the computer.
Step 3: Set the parameters of the HyperTerminal: Baud rate to 115200, Data bits to 8, Parity to None,
and Stop bits to 1.
Step 4: After setting the parameters, click Connect to enter.
x
Quick Connect
Protocol:
The port may be manually entered or selected from the list.
Serial
Flow Control
DTR/DSR
RTS/CTS
XON/XOFF
Save sessionShow quick connect on startup
Open in a tab
Connect Cancel
COM3
115200
8
None
1
Port:
Baud rate:
Data bits:
Parity:
Stop bits:
Name of pipe:
