9 | P a g e
RHINO SERIAL INTERFACE
There is no adapter required for the Rhino Alarm Panels
Plug the one end into the Rhino Panel and the other end into
the Hawk serial port.
TEXECOM SERIAL INTERFACE
Use the serial interface cable along with the adapter board
marked TEXECOM/IDS
Program the Hawk to use the Texecom Serial Alarm Interface
(DTMF – Serial Interface Tab)
The Hawk is connected to COM1 on the Alarm Panel
The following programming is required on the Texecom panel:
1,2,5,8 ON (ENABLE COMMUNICATOR)
0 TEL NO 22 (YES)
1 ACC CODE 3456 (YES)
2 PROTOCOL TYPE = 4 (CONTACT ID)
3 DIALLER ATTEMPTS = 1
4 PARTITION (SELECT PARTITIONS 1 AND 2)
5 SELECT REPORTING OPTIONS
