Fuji Electric FVR-E11S-7EN

9-2
(2) Three-phase 400V input
Item Detail specifications
Inverter type
FVR___E11S-4EN
0.4 0.75 1.5 2.2 4.0 5.5 7.5
Nominal applied motor
*1
[kW]
0.4 0.75 1.5 2.2 4.0 5.5 7.5
Rated capacity
*2
[kVA]
1.0 1.7 2.6 3.9 6.4 9.3 12
Rated Voltage
*3
[V]
Three-phase 380,400,415V/50Hz, 380,400,440,460V/60Hz
(with AVR function)
Rated current
*4
[A]
1.5
(1.4)
2.5
(2.1)
3.7
(3.7)
5.5
(5.3)
9.0
(8.7)
13
(12)
18
(16)
Overload capability
150% of rated output current for 1 min.
200% of rated output current for 0.5s
Output ratings
Rated frequency [Hz] 50, 60Hz
Phases, Voltage
, Frequency
Three-phase 380 to 480 V / 50 to 60Hz
*11
Voltage/frequency
fluctuation
Voltage : +10 to -15% Voltage unbalance 2% or less
*10
Frequency : +5 to -5%
Momentary voltage dip
capability
*5
Operation continues at 300V or higher voltage. When the input voltage
drops below 300V from the rated voltage, operation continues for 15 ms.
Rated current [A]
(With DCR)
0.82 1.5 2.9 4.2 7.1 10.0 13.5
(Without DCR)
*9
1.8 3.5 6.2 9.2 14.9 21.5 27.9
Input ratings
Required power supply
capacity
*6
[kVA]
0.6 1.1 2.1 3.0 5.0 7.0 9.4
Braking torque
*7
[%]
70 40 20
Braking torque
*8
[%]
150
Braking
DC braking
Starting frequency: 0.0 to 60.0 Hz, braking current (0 to 100% in 1%
increment), braking time (0.0 to 30.0 s)
Enclosure(IEC60529) IP20
Cooling method Natural cooling Fan cooling
Mass [kg] 1.1 1.2 1.3 1.4 1.9 4.5
*1 The applicable standard motor indicates the case for a 4P standard motor made by Fuji Electric.
*2 The rated capacity indicates the case for 415V output voltage.
*3 Voltages larger than the source voltage cannot be output.
*4 Amperage values in parentheses () are applicable to operation with 4 kHz or higher carrier
frequencies (F26 = 4 or more) or ambient temperatures exceeding 40 degree C.
*5 Tests at standard load condition (85% load)
*6 Indicates the value when using a DC reactor (DCR).
*7 Indicates the average braking torque for decelerating and stopping a discrete motor from 60 Hz.
(Varies according to the efficiency of the motor.)
*8 Indicates the value with an external braking resistor (option).
*9 Calculated on assumption that the inverter is connected to 500kVA power supply.
*10 Refer to IEC61800-3 5.2.3.
*11 Safe separation for control interface of this inverter is provided when this inverter is installed in
overvoltage category II. Basic insulation for control interface of this inverter is provided when this
inverter is installed in overvoltage category III.
