1-2
(1-2) Overall view (5.5,7.5kW)
(2-1) View of wiring part(4.0kW or below)
A barrier is provided in the main circuit terminal block cover for the P1, P (+), DB and N (-) cable port.
Cut the barrier using nippers or the like before wiring.
Keypad panel
Control cable port
Terminal block cover
(-) cable port
Intermediate cover
L1/R, L2/S, L3/T
(L1/L, L2/N), U, V, W
cable port
Ratings nameplate
Grounding cable port
Keypad panel mounting screw
