15 Appendix
570
Appendix
15
z
If the document size < paper size, it plots at the same scale (100%).
If the origin position of the plotting position is Layout, the document is placed and drawn in
the center. If the origin position is bottom left or center, the origin of the document and the
paper are aligned and drawn.
îš„ If the Document Size is Auto and the Scaling Mode is ACA
The hard clip setting is inactive. The hard clip area is always the advanced hard clip area.
The scaling factor is determined according to the ACA and the paper size. The range for the
ACA for each paper size is as follows:
The maximum scaling factor is 210% of the advanced hard clip area for each paper size and
the minimum scaling factor is 22.5%.
Examples of Combinations of Each Function
The following are examples showing the print results that can be achieved by combining
various functions.
Paper Size
A4 A5 B5
Document
Size
A0 25 100 100
A1 35 25 31
A2 50 35 43
A3 71 50 61
A4 100 71 87
A5 100 100 100
Unit: Percent (%)
Paper
Size
0 Degrees 90 Degrees
Min Value Max Value Min Value Max Value
P2x - P1x P2y - P1y P2x - P1x P2y - P1y P2x - P1x P2y - P1y P2x - P1x P2y - P1y
A4 5485 3828 51200 35733 3828 5485 35733 51200
A5 3828 2648 35733 24720 2648 3828 44088 35733
B5 4723 3297 44088 30773 3297 4723 30773 44088
Unit: Plotter Unit
