Machine Components
53
Product Overview
2
*1 : Only available when the Finisher D4 with Booklet Maker is installed.
*2 : Only available when the Folding Unit (Z and C) is installed.
Note • The Finisher D4 and the Finisher D4 with Booklet Maker are optional. In this guide, the Finisher D4
and the Finisher D4 with Booklet Maker are referred to as the "finisher".
9 Staple cartridges for
booklet*1
There are two staple cartridges installed for Booklet Creation (gutter). Take
the cartridges out when clearing staple jams, or when replacing them with
new ones.
10 Staple waste container Collects waste from the stapler. Remove this cartridge to replace the staple
waste container.
11 Staple cartridge Contains staples. Remove this cartridge when you need to add staples or
clear staple jams.
12 Hole punch waste container Collects waste from the puncher. Remove this when emptying the container.
13 Tri-Fold output tray*2 Delivers tri-folded (C fold and Z fold) copies.
14 Tri-Fold output tray button*2 Press this button to open the Tri-Fold output tray.
15 Left cover Open this cover to access the interior of the machine to clear paper jams.
16 Interface module front cover Open this cover to clear paper jams.
No. Component Function
