Replacing Consumables
93
Maintenance
3
1 Make sure that the machine is not operating,
and open the finisher front door.
2 With grasping the lever [R1] of the staple
cartridge holder, pull the holder to the right,
towards you.
3 With grasping the orange lever, pull out the
staple cartridge.
Note • The staple cartridge is firmly inserted. A slight
force is required to pull the cartridge out of
the finisher.
• When the C3 Finisher Staple Unit 65 Sheets is
installed, pull down the orange lever, and pull
out the staple cartridge.
4 Pinch both sides of the empty staple case with
your fingers (1), and pull out the staple case
from the cartridge (2).
Important • The staple case cannot be removed when the
staples are remained in the staple case.
Forcibly removing the staple case may cause
machine malfunction.
To Next Page
