A.5 Installing Additional Memory 187
5. Insert the memory card into the
connector.Then press the retaining clips
downward until they close.The retaining
clips click into place.
6. Close the rear cover and tighten the screw
loosened in Step 2.
7. Plug in the power cord and switch on the
power by pressing the power switch to
the<|> position.
The installation is now complete.
Note
• You can check whether the memory card is installed correctly by printing out the [Printer Settings] list.
[Memory Capacity] under [General] shows the total memory capacity of the printer (which is the memory
on the controller board (256 MB) plus the memory you just added). For information on how to print the
[Printer Settings] list, refer to “Printing a Report/List” (P. 140).
