Interfaces and connectors
Power On LED II
(see "APM and ACPI system status, energy-
saving modes" chapter)
1
3
Pin Note
1 Power On LED (Anode)
2 Power On LED (Anode)
3 Power On LED (Cathode)
Power supply ATX
1
11
Pin Signal Pin Signal
1 +3.3 V (P3V3P) 11 +3.3 V (P3V3P)
2 +3.3 V (P3V3P) 12 -12 V (P12VN)
3 GND 13 GND
4 +5 V (VCC) 14 PS on (low asserted)
5 GND 15 GND
6 +5 V (VCC) 16 GND
7 GND 17 GND
8 Powergood (high asserted) 18 -5 V (P5VN)
9 +5 V Auxiliary (VCC Aux) 19 +5 V (VCC)
10 +12 V (P12VP) 20 +5 V (VCC)
Fan 1
(system fan - supervised)
1
Pin Signal
1 GND
2 Controlled Fan voltage (0 V, +6 V ... +12 V, max. 1 A)
or fix Fan voltage (+12 V, max. 1 A)
3 Fan sense
A26361-D1520-Z120-1-6319 English - 11
