Interfaces and connectors
The positions of the interfaces and connectors are shown on page "Cover".
The components and connectors marked are not necessarily present on the mainboard.
External ports
The positions of the external ports are shown on page "Cover".
PS/2 keyboard port, purple
Audio input (Line in), light blue
Serial interface, turquoise
PS/2 mouse port, green
Monitor port, blue
Parallel port/Printer, burgundy
LAN
LAN connector (optional)
USB - Universal Serial Bus, black
Audio output (Line out), light green
Microphone jack (mono), pink
LAN connector
The mainboard has an optional Intel 82562EZ/82547EI LAN controller. This LAN controller supports
the transfer rates of 10 Mbit/s, 100 Mbit/s and the LAN controller 82547EI additionally supports
1000 Mbit/s. The LAN controller is equipped with a 2 KB transmission and receiving buffer (FIFO)
and supports WOL function through Magic Packetä. The LAN controller 82547EI supports also
Basic Alert-on-LAN II and Alert Standard Format (ASF). The LAN RJ45 connector has two LEDs
(light emitting diodes).
2
1
LED 1 lights green - a connection exists (e.g. to a hub). LED is blinking green: activity
LED 2 lights differently with the two possible LAN controllers:
Link Mode: the LAN connection is active. WOL mode: a Magic Packet
TM
is being
received.
82562EZ 82547EI 82562EZ 82547EI
10 Mbit/s off off 10 Mbit/s off off
100 Mbit/s yellow green 100 Mbit/s yellow green
1000 Mbit/s - yellow - - -
